LED Controller WiFi RGB+CCT 12-24VDC 5in1 WL5

The WL5 MiLight/MiBoxer WiFi controller is a universal device designed to work with LED strips. The type of the connected LED strip can be set on the controller by connecting to it earlier via a smartphone (RGB+CCT, RGB+W, RGB, CCT, MONO). The WL5 LED controller allows for smooth adjustment of brightness, light color and white light color temperature. The device can work in the range of 12-24V DC and the maximum output current must not exceed 15A (moc 180W with a 12V installation and 360W with a 24V installation). It can be controlled by a remote control or a smartphone application (the WL-BOX2 WiFi bridge is not required). In addition, the controller acts as a repeater, while maintaining a 30m spacing between successive elements, allows for unlimited range.

Compatible products

FUT006
FUT007
S1
S1
S1
FUT096
FUT096B
S2
S2
S2
FUT095
FUT087
FUT087B
FUT088
FUT092
FUT089
FUT089B
B0
B0B
B1
B1
T1
B2
T2
B3
B3B
T3
B4
B4B
T4
B8

Specification

Symbol (EAN13) Input voltage Max. output current  [ A ] Weight  [ kg ] in stock
WL5
(6970602180124)
12 - 24V DC 15 0.078  0  pcs

Dimensions

Files to download

Type Link
Data sheet

Catalog  2023
